Greenbull BX200 Portable Camera Slider
Portable, Firm and Easy-to-use
Equipped with 8-wheel slide car, 0.8-meter elevated leg and 2-meter splicing slide rail, BX200 can bear 50kg, and match large-scale professional camera equipment. It can be stored in roller equipment bag with outstanding portability. It can be equipped with electric control kit to realize remote camera shooting. It is a portable video slide track for professional users
* Appearance design patent: Portable Video Slide (Greenbull BX200 kit)
Patent No.: ZL201730568692.4
* Patent for utility model: a kind of portable video track Patent No.: ZL201721541189.0
* The camera in the picture is for display effect, not included in the product, please buy separately.
Main features
Load bearing 50kg｜2m splicing slide rail｜CNC refined slide car｜elevated support leg｜wireless electronic control kit｜aviation aluminum alloy｜silent rail wheel｜standard 75 & 100 bowl seat｜ optional 150 bowl seat｜anti rollover design｜light rack tripod｜roller equipment bag
8-wheel rail carCNC refined aluminum alloy slide car is equipped with high elastic silent rail wheel and antirollover safety buckle design to enhance the safety in shooting.
Multi aperture pan tilt standIt is equipped with 100&75mm bowl platform base and optional with 150mm bowl platform base. It is inclusive and flexible.
2m spliced slide rail2m spliced aluminum alloy slide can bear 50kg. Precision docking of stainless steel thread can combine a variety of length with light weight and excellent portability.
0.8 m elevated legBX200 has two kinds of support leg – standard type and elevated type. It is stable like a stone and can be equipped with various lampstands, magic legs and tripods.
Roller bagThe whole set of equipment is put into the portable bag of roller equipment, which can be easily carried by single person.
Packing list of BX200 （2m） standard version:
1. Slide Car *1
2. Standard rail 2*2
3. Extended rail: *2
4. Support leg *2
5. Elevated leg (with bag) *4
6. Lamp bracket screw *2
7. Hexagon wrench (5.0mm) *1
8. Safety buckle *2
9. Instruction and warranty card*1
10. Roller bag *1
Performance parameters
Slide car:
Size: 328x375x140mm (length x width x height)
Self-weight: 2.8kg
Bearing weight: 50kg
Pulley: 2 wheels x 4 groups
Bowl platform: 75&100mm (standard configuration), 150mm (optional configuration)
BX200 rail parameters
| Item |
Standard version
|
| Total length of slide track |
2m |
|
Track distance
|
250mm |
|
Pipe diameter
|
32mm
|
|
Length
|
Standard track 667mm; bridge track: 800mm; extended track: 667mm
|
|
Standard track
|
2×2
|
|
Extended track
|
2×1
|
|
|
|
|
|
|
|
|
|
Electronic control
assembly
|
Optional: Video Version, delay photography version
|
|
|
The aperture of the suitable lamp bracket is 5 / 8 ";
There are 3 / 8 "- 16 and 1 / 4" - 20 screw holes at the bottom of the
support leg
|
